Twin Beam Flameproof Emergency Light

Twin Beam Flameproof Emergency Light Specification

Product Type
Emergency Light

Material
Aluminium

Color Temperature
60006500K

Function
Twin Beam Emergency Lighting

Input Voltage
230V

Light Source
LED

Voltage
230 Volt (v)

Base Type
Fixed Surface Mount

Charging Time
10-12 Hours

Charging Voltage
230V AC

Dimension (L*W*H)
400mm x 280mm x 170mm

Weight
7.5 kg

Warranty
Yes

Explosion Proof/Flameproof Rating
IIC/IEC Ex Certified

Cable Entry
Double Compression Cable Gland

Number of Lamps
2 (Twin Beam)

Ingress Protection (IP Rating)
IP66

Backup Time
35 Hours

Body Finish
Epoxy Powder Coated

Indicator
Charging and Battery Low Indicators

Operating Temperature
-10C to +55C

Application
Hazardous Area, Industrial Safety

Compliance
IS/IEC 60079-1/2, CE

Control Mode
Automatic Switch on Power Failure

Mounting
Wall/Surface Mounted

Test Facility
Manual Test Switch

Lumen Output
2 x 6W LED (approx 1200lm)

Glass Cover
Toughened

Twin Beam Flameproof Emergency Light Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Twin Beam Flameproof Emergency Light

PRODUCT SPECIFICATION:

Circuit: LED Driver cum Control Card for instant automatic operation during and on Resumption of Power Failure.
Charging: Constant current Controlled charging circuit including automatic cut-off when the battery gets fully discharged and protection against overcharge.
Lamps: Multiple, High Power Super Bright/Warm White LEDs.
Wattage: 2x12 Watts (appx) for each lamp.
Battery: Rechargeable battery
Degree of protection: Conforms to IP-66 Flame/Weatherproof.

Note: Also available with yellow diffusers for use as Fog Lamps.

Maximum Safety for Hazardous Areas

This Twin Beam Flameproof Emergency Light is engineered for high-risk and hazardous areas such as chemical plants, refineries, and industrial zones. Its explosion proof rating (IIC/IEC Ex certified) and ingress protection (IP66) ensure reliable performance even in the toughest conditions. Whether exposed to dust, water, or chemicals, the epoxy powder-coated aluminum body and toughened glass cover provide superior durability, making it ideal for critical applications.

Efficient and Reliable Illumination

Equipped with two powerful 6W LED lamps, this emergency light provides a combined output of around 1200 lumens, ensuring visibility during emergencies. The unit offers a backup time of 3 to 5 hours, giving ample time for safe evacuation or response during power failures. With automatic switching upon loss of AC supply, the system guarantees immediate lighting when it matters most.

Convenience and User-Friendly Features

Designed with the user in mind, this emergency light incorporates a manual test switch for easy functionality checks, along with charging and battery low indicators for continuous reliability. Its double compression cable gland ensures secure installation, and wall or surface mounting simplifies placement in various settings. The unit supports a wide operating temperature range and charges efficiently within 1012 hours from a standard 230V AC supply.

FAQs of Twin Beam Flameproof Emergency Light:

Q: How is the Twin Beam Flameproof Emergency Light installed?

A: The emergency light is designed for easy wall or surface mounting. It comes with a fixed surface mount base and double compression cable glands for secure cabling. The installation process involves mounting the light on a suitable vertical or horizontal surface in the hazardous area, ensuring proper connection to a 230V AC power supply.

Q: What are the main benefits of using this emergency light in hazardous areas?

A: This flameproof emergency light offers IIC/IEC Ex explosion proof certification and IP66 ingress protection, making it exceptionally safe for use in hazardous locations. Its robust aluminum body, toughened glass, and reliable LED illumination reduce risks while ensuring that critical areas remain lit during emergencies.

Q: When does the emergency light automatically switch on?

A: The emergency light is equipped with an automatic control system that activates the lamps as soon as it detects a power failure. This ensures uninterrupted lighting in the event of unexpected outages, providing essential illumination during emergencies.

Q: Where is this emergency light best suited for application?

A: Its ideal for hazardous and industrial environments such as refineries, chemical plants, process industries, and any locations classified as explosion prone due to flammable gases or dust. The durable IP66 flameproof construction ensures it withstands tough industrial conditions.

Q: What is the backup time and charging process for the light?

A: The emergency light provides a backup time of 35 hours once fully charged. Charging takes 1012 hours using a 230V AC supply. The integrated indicators display charging and battery status, while the manual test facility allows for regular performance checks.

Q: How can users monitor and maintain the unit?

A: Charging and battery low indicators clearly show the devices status at a glance. The manual test switch enables users to perform routine operational tests to ensure system readiness, supporting consistent maintenance and peace of mind.
