WL-I Industrial Emergency Light Maintained

WL-I Industrial Emergency Light Maintained Specification

Product Type
Industrial Emergency Light (Maintained)

Material
Metal Body and Plastic Components

Color Temperature
6000-6500K

Function
Maintained Operation (continuous light during mains and emergency)

Input Voltage
220-240V AC, 50Hz

Light Source
High Brightness LED

Voltage
220V

Base Type
Wall Mountable

Charging Time
8-12 Hours

Charging Voltage
220-240V

Dimension (L*W*H)
Approx. 340 x 200 x 90 mm

Weight
Approx. 2.1 kg

Application
Factories, Warehouses, Industrial Plants, Commercial Spaces

Lamp Housing
Powder-coated corrosion resistant steel

Installation
Wall or ceiling mount

Battery Type
Sealed Lead Acid Rechargeable Battery

Mounting Type
Surface Mountable

Ingress Protection
IP20

Operation Mode
Automatic switch to battery backup during power failure

Backup Duration
2-3 hours (on full charge)

Indicator
LED charging and mains indicator

Safety Feature
Overcharge & Deep Discharge Protection

About WL-I Industrial Emergency Light Maintained

PRODUCT SPECIFICATION:

Circuit: Specially designed solid state Hi high-frequency inverter Circuits with well-protected electronic circuitry.
Charging:CVCC, SCR Controlled charging circuit including automatic Cut off when battery gets fully discharged and protection against overcharging with trickle & Boost Charge.
Lamps: 1x18/20W LED Tubes
Input Voltage: 110-290 V -/+ 10 %
IP Rating: IP 65
Options:Maintained (AC/DC) Working (Working on both tubes during power availability and working only with one or both tubes as required during power failure.)

Rugged and Reliable Construction

Built with a powder-coated, corrosion-resistant steel body merged with plastic components, the WL-I Industrial Emergency Light withstands the rigors of industrial and commercial applications. Its IP20 ingress protection makes it suitable for indoor installations, and its dimension and lightweight build ensure easy handling.

Automatic Battery Backup During Emergencies

This emergency light features automatic switching to battery backup during power failures, ensuring uninterrupted illumination. Once mains power is restored, the system automatically recharges the sealed lead acid battery within 8-12 hours, preparing the light for the next emergency event.

Versatile Installation for Industrial Spaces

Designed for surface mounting, the WL-I can be easily installed on walls or ceilings in factories, warehouses, and various commercial settings across India. With both maintained operation and instant response to power interruptions, it supports safety and compliance needs.

FAQs of WL-I Industrial Emergency Light Maintained:

Q: How do I install the WL-I Industrial Emergency Light in my facility?

A: The WL-I can be surface-mounted on either walls or ceilings using standard installation hardware. Carefully follow the included instructions to connect the light to the 220-240V AC power supply and securely fix it in your chosen location.

Q: What happens if there is a power failure?

A: When mains power is lost, the light automatically switches to battery backup mode to provide continuous illumination for 2-3 hours, ensuring that critical areas remain safely lit during emergencies.

Q: Where can I use the WL-I Industrial Emergency Light?

A: This model is ideal for factories, warehouses, industrial plants, and commercial spaces that require reliable emergency lighting. Its robust design and consistent performance make it suitable for various large-scale settings.

Q: What benefits does the overcharge and deep discharge protection offer?

A: Overcharge and deep discharge protection helps extend the overall lifespan of the sealed lead acid battery while maintaining safe and efficient operation, reducing the need for frequent maintenance or replacements.

Q: How long does it take to fully recharge the battery after use?

A: After a power interruption, the sealed lead acid rechargeable battery requires 8-12 hours to completely recharge when connected to its designated charging voltage of 220-240V.

Q: What type of light source does this emergency light use?

A: The WL-I is equipped with high-brightness LED lamps, offering a cool white color temperature (6000-6500K) that ensures clear and effective illumination during both normal and emergency operation.
